MP150 Series
Product Details
- Safety Approvals: Medical 60601-1
- Footprint: 5 x 3 x 1.4”
- Construction: Class I or Class II
- High Efficiency: 90% Typical At Full Load
- Output: 5VSDB @ 0.5A
- Input: Universal AC Input With Active PFC
- Emissions: EN55011 / FCC Part 15J Class B
- Warranty: 3 Years
- Additional Feature: Remote On/Off, Power Fail, Remote Sense
150 Watt Medical Desktop Power Supply
Reliability and value, the 150W 3 x 5″ Open Frame is the industry-standard workhorse. Phasium’s high-efficiency PF + LLC put’s out less heat and has inherently low EMI. Features include a 12V fan output and remote on/of. Class I and Class II construction is available.
| MODELS | MAIN OUTPUT VOLTAGE |
OUTPUT CURRENT (Convection) | OUTPUT CURRENT (FORCED AIR) | STANDBY OUTPUT | FAN OUTPUT |
| MP150-12 | 12V | 12.5A | 16.7A | 5V 400mA | 12V 0.4A |
| MP150-19 | 19V | 7.9A | 10.5A | 5V 400mA | 12V 0.4A |
| MP150-24 | 24V | 6.3A | 8.3A | 5V 400mA | 12V 0.4A |
| MP150-28 | 28V | 5.4A | 7.1A | 5V 400mA | 12V 0.4A |
| MP150-48 | 48V | 3.1A | 4.2A | 5V 400mA | 12V 0.4A |
Input Voltage– 90-264 VAC (Universal)
Efciency- 90% typical at 115/230 VAC, full load
Leakage Current– <100µA @ 264VAC
Operating Temperature– 0°C ~ +40°C
Protection– Internal T5A / 250V Fuse (Line & Neutral)
Line Regulation– ±0.5%
Isolation- Input to Output: 4000 VAC
Input to Ground: 1500 VAC
Output to Ground: 500 VDC
Load Regulation– ±2% For Main & 5VSDB ; ±10% For Fan
MTBF– 300K Hours, Mil-217F at 25 °C, full load
