MANGO25S Series
Product Details
- Safety Approvals: Medical 60601-1
- Footprint: 3.27 x 1.69 x 1.27"
- Construction: Class II
- High Efficiency: Level VI
- Compliance: CEC 2008 / ErP2 / EISA 2007
- Warranty: 3 Year
- Emissions: EN55011 / FCC Part 15J Class B
- AC Plug Options:: US, UK, AUS or EU Wall Mount Packages
25 Watt Medical Desktop Power Supply
PHASIUM adapters are the supply chain solution for reliability and low cost. The MANGO25S wall-mount medical adapters deliver 25 watts (continuous) of DC power to your medical or IT device. Available in international plug styles, the new MANGO25S series meets all Medical and Commercial compliance requirements including 4th Edition EMC and Level VI Efficiency.
| MODELS | OUTPUT VOLTAGE | OUTPUT CURRENT | RIPPLE & NOISE (MAX) | MAX TOTAL REGULATION |
| MANGO25S-9xy | 9V | 2.7A | 90mV | ±5% |
| MANGO25S-12xy | 12V | 2.1A | 120mV | ±5% |
| MANGO25S-15xy | 15V | 1.7A | 150mV | ±5% |
| MANGO25S-19xy | 19V | 1.3A | 190mV | ±5% |
| MANGO25S-24xy | 24V | 1.1A | 240mV | ±5% |
| MANGO25S-28xy | 28V | 0.9A | 280mV | ±5% |
Leakage Current – <100 µA @ 264VAC / 60Hz
Line Regulation- ±1.0%
Load Regulation- ±5%
Efficiency- 80-84% typical at 115/230 VAC, full load
Operating Temperature- 0°C ~ +40°C
Isolation- Input to Output 4000 VAC
MTBF- 200K Hours, Mil-217F at 25 °C, full load
